2026 Hyundai IONIQ 5 N near Raeford, NC
The 2026 Hyundai IONIQ 5 N represents a performance-focused evolution of the brand’s electric vehicle platform. Developed under the N performance division, this model integrates dual electric motors, a high-capacity lithium-ion battery system, electronically controlled suspension, and advanced driver assistance technologies into a unified all-wheel-drive configuration. It is engineered to deliver measurable acceleration, controlled handling dynamics, and rapid charging capability while maintaining the structural and safety standards expected of a modern electric crossover. Every specification is defined by quantifiable performance metrics and integrated system coordination.
Dual-Motor Power and High-Output Capability
The 2026 Hyundai IONIQ 5 N operates with a dual permanent-magnet synchronous motor configuration. This setup supports all-wheel drive and delivers a combined maximum output of 448 kW, equivalent to 601 horsepower. When N Grin Boost is activated, total output increases to 478 kW, or 641 horsepower. Torque output measures 740 Nm, equivalent to 545 lb-ft, and increases to 770 Nm, or 568 lb-ft, with N Grin Boost engaged.
The drivetrain uses a single-speed reduction gear transmission paired with shift-by-wire functionality. The front axle incorporates a dog clutch disconnector system, while the rear axle operates without a clutch. The front gear ratio measures 2.263 and the rear gear ratio measures 2.265, with a final gear ratio of 4.706. Lubricant oil capacity is 3.2 liters for the front and 3.4 liters for the rear. A 12-volt non-traction electrical system supports auxiliary functions.
Drive Mode Select allows drivers to choose between Eco, Normal, Sport, N, N Custom 1, and N Custom 2 modes using steering wheel-mounted controls. These modes adjust power delivery, steering calibration, suspension settings, and regenerative braking response to align with selected driving preferences.
High-Voltage Battery Architecture and Charging Systems
The 2026 Hyundai IONIQ 5 N uses an 84.0 kWh lithium-ion battery system supplied by SK Innovation. The battery operates at 697 volts and features a 2P192S structure. Battery weight measures 1,071 pounds. Energy density is rated at approximately 78.5 Wh per pound. Maximum discharge power is rated at 535 kW and maximum charging power at 432 kW.
An integrated battery preconditioning function supports thermal optimization prior to high-demand driving or fast charging. The model is equipped with an ultra-fast charging system capable of supporting up to 800-volt, 350 kW DC charging. Under these conditions, charging from 10 percent to 80 percent can be completed in approximately 18 minutes. Using 150 kW DC fast charging at 400 volts, the same 10 percent to 80 percent charging window requires approximately 30 minutes. When connected to a 50 kW DC charger, charging from 10 percent to 80 percent requires approximately 1 hour and 21 minutes. Standard AC Level II charging at 240 volts requires approximately 7 hours and 20 minutes for a 10 percent to 100 percent charge.
The charge port uses a North American Charging Standard configuration and is located on the rear passenger-side quarter panel. A heat pump and PTC heater are included to support efficient cabin and battery thermal management in varying temperature conditions. Vehicle-to-Load capability allows two-way onboard charging through an external accessory adapter, enabling the vehicle to power compatible external devices.
Disclaimer: Approximately 20 minutes to charge from 10% to 80% on a 350-kW, 800V DC ultra-fast charger using the CCS adapter included with the 2026 IONIQ 5. Actual charging time varies based on a number of factors, including current battery charge level, output of the charging unit, vehicle and battery settings, battery temperature and outside temperature. Ultra-fast charging stations are provided by independent companies and availability is not guaranteed.
Suspension Systems and Structural Engineering
The chassis of the 2026 Hyundai IONIQ 5 N uses a unibody monocoque structure constructed from advanced high-strength steel and high-tensile steel. The front suspension employs a MacPherson® strut design, while the rear suspension uses a multi-link five-link configuration. Both front and rear are equipped with high-performance dampers integrated into an electronically controlled suspension system.
The electronically controlled suspension continuously adjusts damping force based on drive mode selection and vehicle inputs. This supports improved body control during acceleration, braking, and cornering while maintaining ride stability. Steering uses a rack-and-pinion configuration with motor-driven power steering mounted to the rack. The overall steering ratio is 12.54 to 1. Steering requires 2.29 turns from lock to lock, and curb-to-curb turning diameter measures 40.7 feet. The steering wheel measures 14.5 inches in diameter.
Minimum ground clearance is 5.6 inches. The wheelbase measures 118.1 inches. Overall length is 185.6 inches, width is 76.4 inches, and height is 62.4 inches. Front tread width measures 65.6 inches, and rear tread width measures 65.8 inches. Front and rear overhangs measure 34.3 inches and 33.3 inches, respectively. The coefficient of drag is rated at 0.313.
High-Performance Braking and Regenerative Systems
The braking system of the 2026 Hyundai IONIQ 5 N is engineered for sustained high-speed deceleration. The front braking system uses ventilated discs measuring 400 millimeters in diameter and 34 millimeters in thickness, equivalent to 15.7 inches by 1.3 inches. The rear braking system uses ventilated discs measuring 360 millimeters in diameter and 20 millimeters in thickness, equivalent to 14.2 inches by 0.8 inches. The front utilizes a four-piston fixed caliper design, while the rear uses a single-piston sliding caliper.
Integrated Electronic Brake technology replaces a conventional vacuum booster system and works in coordination with regenerative braking. Anti-lock Braking System includes four wheels, four channels, and four sensors. Electronic Brake-force Distribution, Brake Assist, Hillstart Assist Control, and Electronic Stability Control are standard. Regenerative braking levels are adjustable, and N e-Shift virtual gear shift paddles allow the driver to simulate stepped gear transitions during deceleration.
Exterior Aerodynamics and Performance Design
The 2026 Hyundai IONIQ 5 N incorporates performance-oriented exterior enhancements that support airflow management and cooling efficiency. Active grille shutters and active front air flaps adjust automatically to optimize aerodynamic efficiency or improve airflow to cooling components. The body features gloss black bumpers and side skirts with luminous orange accents, wide fender arches, and N-exclusive side sills. A rear spoiler integrated with an LED center high-mounted stop lamp enhances aerodynamic balance.
The vehicle rides on 21 by 9.5J forged alloy wheels weighing approximately 32 pounds per wheel. Tires are 275 by 35R21 Pirelli P ZERO PZ4 HN-spec units equipped with PNCS and ELECT plus technology for performance traction and reduced road noise. LED projector headlights, LED daytime running lights, automatic headlights, High Beam Assist, LED taillights, and LED interior lighting are standard. The panoramic fixed glass Vision Roof includes a sunshade.
Interior Technology and Digital Integration
The interior accommodates five occupants and uses Eco Alcantara® and H-Tex® seating surfaces. N lightweight sport bucket seats include illuminated N logos. Front seats are six-way manually adjustable and include heating and ventilation functions. The rear bench seat features a 60 by 40 split fold-down design with sliding and reclining functionality.
Instrumentation includes a 12.3-inch digital instrument cluster with N mode and EV Technology Display. The infotainment system features a 12.3-inch color touchscreen with navigation, AM, FM, SiriusXM®, and HD Radio™ functionality. Wireless Android Auto™ and Apple CarPlay® integration is standard. The audio system is a Bose® premium configuration with eight speakers and an external amplifier. Wireless phone charging supports 15 watts. Multiple USB Type-C ports are installed across both rows.
Smart Cruise Control with Stop and Go functionality is included with machine learning capability. Hyundai Digital Key 2 Premium uses NFC, Bluetooth® Low Energy, and Ultra Wideband technology. Bluelink®+ connected services, remote charge access, Wi-Fi hotspot capability, and Hyundai Pay integration are included.
Advanced Safety and Driver Assistance Systems
The 2026 Hyundai IONIQ 5 N incorporates a comprehensive suite of active and passive safety systems. Forward Collision-Avoidance Assist 2 includes detection for vehicles, pedestrians, cyclists, junction turning, junction crossing, lane change oncoming, lane change side detection, and evasive steering assist. Blind-Spot Collision-Avoidance Assist, Blind-Spot View Monitor, Surround View Monitor, Rear Cross-Traffic Collision-Avoidance Assist, and Parking Collision-Avoidance Assist Reverse are included.
Lane Keeping Assist, Lane Following Assist, Intelligent Speed Limit Assist, Driver Attention Warning, Forward Attention Warning, Safe Exit Assist, and Navigation-based Smart Cruise Control with Curve Control are standard. Highway Driving Assist 2 integrates adaptive cruise and lane centering support. Advanced Rear Occupant Alert uses radar detection technology.
Passive safety systems include advanced front airbags, front seat-mounted side-impact airbags, and side curtain airbags with rollover sensors. Seatbelt pretensioners and load limiters are installed at all outboard seating positions. Rear LATCH anchors, child safety locks, Vehicle Stability Management, a Tire Pressure Monitoring System with individual tire indicators, and an electronic shift lock system are standard.
Visit ALM Hyundai Lumberton for a Test Ride
We invite you to experience the 2026 Hyundai IONIQ 5 N firsthand at ALM Hyundai Lumberton near Raeford, NC. This model delivers 641 horsepower capability, electronically controlled suspension, high-capacity 84.0 kWh battery architecture, and an integrated suite of advanced safety technologies in a single all-wheel-drive platform. During a test drive, you can evaluate its acceleration response, regenerative braking system, steering precision, and digital instrumentation interface under controlled conditions. Our team will provide a detailed walkthrough of its charging systems, drive mode configurations, and advanced driver assistance features to ensure you understand its full technical capabilities. Contact us to schedule your appointment and examine the engineering and performance systems of the 2026 Hyundai IONIQ 5 N in person.
